PowerSeries Neo Installation Guide

Aux Loading and Battery Selection

HS2128/HS2064/

HS2032/HS2016

Board current draw 85mA

UL Residential Burg

ULC Residential Burg

UL Commercial Burg

UL Resi Fire

UL Home Health Care

ULC Resi Fire

ULC Com Burg

ULC Fire Monitoring

EN50131

Grade 2/Class II

Max AUX (NSC) current

0.7A 0.7A 0.5A* 0.5A 0.5A

Max BELL (Alarm) current

0.7A 0.7A 0.7A

0.7A (no local alarm

notification allowed, only

remote transmission to SRC)

0.7A

UL/ULC Listed enclosure

PC500C

PC5003C

CMC-1

PC4050CAR

PC5003C

PC4050CR (red/transfomer

mounted inside)

PC5003C

Power UC1

Transformer requirements

16.5V/40VA (plug in type)

PTC1640U (USA)

PTC1640CG (CAN)

FTC1637 (cUL listed)

16.5V/37VA (Hardwired

type, mounted inside the

enclosure or outside using

electrical box)

16.5V/40VA (hardwired

type, mounted inside the

cabinet)

Battery Capacity requirements 7Ah 7Ah

14Ah (2 x 7Ah in

parallel)

14Ah (2 x 7Ah in parallel) 7Ah

Standby Time

UL: 4 hours

ULC: 24 hours

4 hours 24 hours 24 hours 12 hours

Alarm time 4 minutes 15 minutes

4 min (UL resi fire)

5 min (Home Health

Care and ULC Resi Fire)

5 minutes (Alarm

Transmission only)

N/A

Recharging current setting 400mA, 700mA 400mA, 700mA 400mA, 700mA 400mA, 700mA 400mA, 700mA

(*) For UL Residential Fire Installations, using hardwired CO Alarm Detectors, the maximum discharge current shall be limited to 250mA to ensure 24h standby

operation followed by 4 minute CO alarm notification then followed by an additional 12h of CO Alarm notification.

SIA False Alarm Reduction Installations: Quick Reference

Minimum required system consists of one control unit model HS2128 or HS2064 or HS2032 or HS2016 and any one of the compatible listed keypads: HS2LCDRF9,

HS2LCDRFP9, HS2ICNRF9, HS2ICNRFP9, HS2LCD, HS2LCDP, HS2ICN, HS2ICNP, HS2LED HS2TCHP.

The following wireless keys can also be used in SIA compatible installations: PG9929, PG9939,PG9949.

Note: For models PG9929 and PG9939, the panic/emergency key shall be disabled for SIA compliant installations.

For a list of the default values programmed when the unit is shipped from the factory, and for other programming information, refer to the following table.

The following optional subassembly modules also bear the SIA CP-01-2010 classification and may be used if desired: HSM2108 zone expander, HSM2208 PGM

output module, HSM2300 auxiliary power supply, HSM2204 output module, HSM2HOST9 2-way wireless transceiver, PG9901 indoor siren, PG9911 outdoor siren,

and 3G2080(R)E/ TL2803G(R)E/ TL280(R)E cellular and PSDN communication module.

Caution

l For SIA FAR installations use only modules/devices that are listed on this page.

l Fire Alarm Verification feature (Auto Verified Fire Zone type [025]) is not supported on 2-wire smoke detectors zones, model FSA-210B(T)(S)(ST)(LST)(R)

(RT)(RD)(RST)(LRST). This feature may be enabled for 4-wire smoke detectors only (FSA-410B(T)(S)(ST)(LST)(R)(RT)(RST)(LRST) and wireless detect-

ors PG9916/PG9926). The fire alarm delay is 60s.

l Call Waiting Cancel (Section [382], option 4) on a non-Call Waiting line will prevent successful communication to the supervising station.

l All system smoke detectors must be tested annually by conducting an Installer Walk Test. Prior to exiting Walk Test mode, a sensor reset must be done on the sys-

tem, [*][7][2], to reset all latching 4-wire smoke detectors. Refer to the installation instructions supplied with the detector for details.

Notes

l Programming at installation may be subordinate to other UL requirements for the intended application.

l Cross zones have the ability to individually protect the intended area (e.g. motion detectors which overlap).

l Cross zoning is not recommended for line security Installations nor is it to be implemented on exit/entry zones.

l This control panel has a communication delay of 30 seconds. It can be removed or increased up to 45 seconds by the end user with installer consultation.
