057-001 720 Operating Instructions Issue 3.1 20/12/2005 AM - 13 -
Parameter Minimum Maximum Default
Outputs
27 - Aux Output 1 0 15 1
Possible selections : 0 - Unused
1 - Preheat Mode 0
2 - Air Flap
3 - Close Generator
4 - Energise to stop
5 - Engine Running
6 - Shutdown Alarm
7 - System in auto
8 - Auxiliary input 1 active
9 - Auxiliary input 2 active
10 - Preheat mode 1
11 - Preheat mode 2
12 - Preheat mode 3
13 - Warning Alarm
14 - Common Alarm
15 - Fail to start
28 - Aux Output 2 0 15 14
Possible selections : 0 - Unused
1 - Preheat Mode 0
2 - Air Flap
3 - Close Generator
4 - Energise to stop
5 - Engine Running
6 - Shutdown Alarm
7 - System in auto
8 - Auxiliary input 1 active
9 - Auxiliary input 2 active
10 - Preheat mode 1
11 - Preheat mode 2
12 - Preheat mode 3
13 - Warning Alarm
14 - Common Alarm
15 - Fail to start
NOTE:- The ‘preheat modes’ selectable for configurable outputs and LCD indicators
perform the following actions :
Preheat mode 0 - Preheat during preheat timer, ceasing at end of preheat timer.
Preheat mode 1 - Preheat during preheat timer and continue until engine stops cranking.
Preheat mode 2 - Preheat during preheat timer and continue until the safety delay timer
has expired.
Preheat mode 3 - Preheat during preheat timer and continue until the warming timer has
expired.
In addition, in all preheat modes, preheat takes place during the crank rest timer between
crank cycles.
