Product Overview
20MC50M00 E5
2020-10-20
22
Figure 4. Product label
Figure 5. DIN-Rail system label
1.6 Identification of DIN-Rail Systems
On a DIN-Rail system you can find the system label on the left side panel of the system
housing. Depending on your DIN-Rail system configuration, not all of the individual
modules have a separate product label (see Position of DIN-Rail product label (back
view).
Figure 6. Position of DIN-Rail system label
Article No.:
01AXXX-00
Serial No.:
000001
Rev.: 00.00.00
Revision numberSerial number
Complete article number
Article No.:
01AXXX-00
Serial No.: 000001
Rev.: 00.00.00
Complete article number
Serial number
Revision number
