duagon MC50M - MEN Menu Sub-Functions and BMC Settings

UEFI Firmware
20MC50M00 E5

2020-10-20
65
4.3.2.1 MEN Menu – Sub-Functions
Table 26. UEFI firmware: MEN Menu
4.3.2.2 MEN Menu – Sub-Menu BMC Settings
In the BMC Settings sub-menu you can find board information that is read out via the
Board Management Controller (BMC), as well as the following sub-functions:
Table 27. UEFI firmware: Sub-menu BMC Settings
Function Options
Setup Mode Standard
Extended
Sub-menu Function Options
MEN BMC Settings WatchDog Disabled
1 min
2 min
5 min
10 min
15 min
20 min
30 min
Power Resume Mode On
Off
Former State
EXT_PWRGD Mode Check at Start-Up only
Check always
EXT_PS_ON Mode Always on
Switched
RESET_IN Enabled
Blocked
MEN BMC Registers For information: displays
values from the BMC, e.g.
error information
