Ducati 996R User Manual

22
E
Side stand (fig. 15)
Important
Before lowering the side stand, make sure that the
bearing surface is hard and flat.
Do not park on soft or pebbled ground or on asphalt melt
by the sun heat and similar or the motorcycle may fall
over.
When parking in downhill road tracts, always park the
motorcycle with its rear wheel facing downhill.
To pull down the side stand, hold the motorcycle
handlebars with both hands and push down on the thrust
arm (1) with your foot until it is fully extended. Tilt the
motorcycle until the side stand is resting on the ground.
Important
Do not sit on the motorcycle when it is supported
on the side stand.
To move the side stand to its rest position (horizontal
position), tilt the motorcycle to the right and, at the same
time, lift the thrust arm (1) with your foot.
Note
Check for proper operation of the stand mechanism
(two springs, one into the other) and the safety sensor (2)
at regular intervals.
1
2
Warning
The motorcycle can be started only if the side stand
is up as its safety device prevents engine start when the
stand is down.
fig. 15
ProCarManuals.com

Ducati 996R Specifications

General

Displacement	998 cc
Compression Ratio	11.5:1
Torque	105 Nm (77.4 lb-ft) @ 8, 000 rpm
Transmission	6-speed
Frame	Tubular steel trellis
Front Brakes	2 x 320 mm discs, 4-piston calipers
Rear Brakes	Single 220 mm disc, 2-piston caliper
Seat Height	790 mm (31.1 in)
Engine Type	Liquid-cooled, 4-stroke, L-twin cylinder, Desmodromic DOHC, 4 valves per cylinder
Power	101 kW (136 hp) @ 10, 200 rpm
Fuel System	Fuel injection
Rear Suspension	Öhlins fully adjustable monoshock
Fuel Capacity	17 liters (4.5 gallons)
Bore x Stroke	100 mm x 63.5 mm
Front Suspension	Öhlins 43 mm upside-down fork
