SECTION 5 - ELECTRICAL DESCRIPTION & ADJUSTMENTS
KEY
ABBREVIATION DESCRIPTION
O.L. Main motor thermal overload relay
Key Main key switch
PB-1 Cut push button 1
PB-2 Cut push button 2
PB-K Knife change switch
LS-D Knife bottom position switch
LS-U Clamp pressure top position switch
LS-C Foot pedal switch
LS-E Backgauge rear safety switch
NC-1 Signal from MKII control
A Photo electric control (optional)
D Knife down relay
U Knife up relay
C Clamp pressure relay for the foot pedal
M Main motor control
T1 Knife adjustment timer
ML Motor pilot light
CL Cutting line light
TR Main transformer
RF Clutch rectifier circuit
BZ Buzzer
P Main motor clutch
Table 3 - Main Electrical Diagram Key
660P CUTTER
5 - 7
