7. Connection to the factory-own vacuum unit
The suction unit facilitates the precise feeding and positioning of the
workpiece on the work table 1.
–
Connect the hose of the factory-own vacuum unit to the connection
valve 3.
Note:
In case no factory-own vacuum unit is available, the vacuum device
(Order No. 0745 597964) has to be ordered in addition.
ATTENTION !
When mounting the vacuum device (side-channel blower) it is
absolutely necessary to exchange the joint ring 2 (black) at the
connection valve against a filter ring (white) included in the
accessories.
