5. Electrical connection
ATTENTION!
Any work on the electrical equipment of the sewing unit must
only be carried out by electricians or correspondingly instructed
persons.
The mains plug must be pulled out.
5.1 Connecting the control panel DACIII
–
Carefully insert plug 1 into the rear panel of the control panel.
–
Tighten the screws 2 of plug 1.
5.2 Connecting the external bobbin winder
–
Insert the plug of the bobbin winder into the socket 3 underneath
the table top and secure with a cap nut.
–
Connect the potential compensation cable 4.
