DYNACORD
20
Use the <SELECT> buttons to navigate to the Port parameters. Use the VALUE up/down buttons to select a user preset
(U01 to U30), factory preset (F01 to F60) or Off if no preset should be loaded.
The Control Port Contacts parameter is used as a display only and corresponds to the binary values of individual pins,
ie - on/off.
SIGNAL GENERATOR
The integrated signal generator of the DSP 600 can generate following signal types:
This window allows editing the generated signal type and signal level for each input channel.
The selected type is always used for both input channels. The Frequency parameter is only available when Type: Sine is
selected.
INPUT
This window is where the audio input can be configured.
Use the <SELECT> buttons to navigate to the Audio parameter. Use the VALUE up/down buttons to choose between
Analog and Digital input. When using the analog input the -6dB PAD can be activated. The activated -6dB PAD is indicat-
ed by the -6dB LED on the DSP 600 rear panel.
For each of the two audio inputs a gain can independently be set (-60 dB to +12 dB). This can be useful if the level of
two mono signals should be adjusted, without editing the presets.
DISPLAY
This window allow the user to adjust the contrast preferences of the LCD screen and the brightness of the front panel
buttons to compensate for different lighting conditions that may be encountered within different venues. Additionally a
screensaver can be activated.
Use the < SELECT > buttons to navigate to the Contrast parameter. Use the VALUE up/down buttons to choose between:
-10 to +10 LCD contrast. Use the < SELECT > buttons to navigate to the Brightness parameter. Use the VALUE up/down
buttons to edit the brightness of the buttons. Use the < SELECT > buttons to navigate to the Screensave parameter. Use
the VALUE up/down buttons for enabeling or disabeling the screen saver.
F
IRMWARE
This window displays the firmware version currently running on the DSP 600.
•Sine signal
•White Noise
• Pink Noise
