Leaders in Pipeline Survey Systems
OPERATOR’S MANUAL
Issue 4.04 - 1207 11
Overhead Locator Bar
Pipeline Position indicator
GPS position
Signal strength indicator
Pipeline Diameter
Distance to Pipeline
Approx. Depth to centre or cover
Approx. Current
Where possible, all displays are language independent, with graphic icons representing features
or functions:
Depth to Centre
Depth to top (cover)
Current
Attenuation
Chainage
Distance
Symbols relating to landscape
features such as trees, walls,
fences, roads, rivers, pylons, etc
Symbol for GPS
Fig. 6 – The Search Screen Mode Display Screen
