OPERATOR’S MANUAL
Issue 4.04 - 1207 22
3.2. Signal Generator (SG)
Signal Generator specifications
Weight
14.5 kgs (32lbs)
Size
33 x 26 x 23cm (13 x 10 x 9”)
Construction
Aluminium drawn case with hinged storage lid
Sealing (Protection Class)
IP66 (closed) / IP65 (open)
Rechargeable batteries
3 x 12v – 7Ahr sealed lead/acid
External power
11.5 to 18v DC
Maximum output
750mA (RMS) AC coupled at 937.5Hz on internal batteries
1000mA (RMS) AC coupled at 937.5 Hz with external power
Survey time
(on internal batteries)
(on external power)
8 hrs at 600mA
Indefinite depending on capacity of power source
Operating temperature range
-20 to +40oC (-4 to +104oF)
NOTE: battery capacity reduces at low temperatures
Connectors
• 2 x shrouded 4mm output sockets
• 1 x multi-pole charger and external power socket
