• Full compatibility with DCAPP for Excel included in C-SCAN 2000
• Software upgradeable via PC
For more details of the display mode screen and the keypad layout see Figs. 6 and 7 below.
Where possible, all displays are language independent, with graphic icons representing
features or functions:
Depth to Centre
Depth to top (cover)
Current
Attenuation
Chainage
Distance
Symbols relating to landscape
features such as trees, walls,
fences, roads, rivers, pylons, etc . . .
Symbol for GPS
To Next Page
