Dynalog C-SCAN 2010 - Page 12

Leaders in Pipeline Survey Systems
2 - 10
OPERATING MANUAL
PART 1 – OPERATION
AVW 150203 – 2010O&MPt1-Sec2.DOC
Overhead Locator
Pipeline Position indicator
GPS position
Signal strength indicator
Pipeline Diameter
Distance to Pipeline
Approx. Depth to centre
or cover
Approx. Current
Fig. 6 – the Search Mode Display screen
