Dynapac CC1300 - Weights and Volumes; Working Capacity; General

Technical specifications
ICC1300-1EN3.pdf 2011-10-10
Weights and volumes
WeightsWeights
Weight CECE, Standard
equipped roller
3900 kg 8,600 lbsWeight CECE, Standard
equipped roller
3900 kg 8,600 lbs
Fluid volumesFluid volumes
Fuel tank 50 liters 52.9 qts
Fuel tank 50 liters 52.9 qts
Water tank 200 liters 211.4 qtsWater tank 200 liters 211.4 qts
Working capacity
Compaction dataCompaction data
Static linear load 14,5 kg/cm 81.2 psiStatic linear load 14,5 kg/cm 81.2 psi
Amplitude 0,5 mm 0.019 inAmplitude 0,5 mm 0.019 in
Vibration frequency 52 Hz 3,120 vpmVibration frequency 52 Hz 3,120 vpm
Centrifugal force 33 kN 7,425 lbCentrifugal force 33 kN 7,425 lb
Note: The frequency is measured at high revs. The
amplitude is measured as the real value and not
the nominal.
PropulsionPropulsion
Speed range 0-10 km/h 0-6.2 mphSpeed range 0-10 km/h 0-6.2 mph
Climbing capacity (theoretical) 36 %Climbing capacity (theoretical) 36 %
General
EngineEngine
Manufacturer/Model Kubota V2203Manufacturer/Model Kubota V2203
Power (SAE J1995) 34 kW 45 hpPower (SAE J1995) 34 kW 45 hp
Engine speed 2600 rpmEngine speed 2600 rpm
Electrical systemElectrical system
Battery 12V 74AhBattery 12V 74Ah
Alternator 12V 60AAlternator 12V 60A
Fuses See the Electrical system
section - fuses
Fuses See the Electrical system
section - fuses
16
