Dynapac CC1300 - Maintenance Schedule; Service Points and Schedule Intervals

Maintenance - Maintenance schedule
ICC1300-1EN3.pdf2011-10-10
Maintenance - Maintenance schedule
Service and maintenance points
19
11
1
2 3 4 5
6
7
8
9
10
12
13
14
15
16
17 18
Fig. Service and maintenance points
1. Fuel tank 8. Sprinkler system 15. Steering joint1. Fuel tank 8. Sprinkler system 15. Steering joint
2. Refueling 9. Scrapers 16. Steering cylinder bracket2. Refueling 9. Scrapers 16. Steering cylinder bracket
3. Cooler 10. Shock absorbers and
attachment screws
17. Filler plugs/Drum3. Cooler 10. Shock absorbers and
attachment screws
17. Filler plugs/Drum
4. Air cleaner 11. Hydraulic fluid refilling 18. Oil level in drum4. Air cleaner 11. Hydraulic fluid refilling 18. Oil level in drum
5. Battery 12. Hydraulic fluid tank 19. Emergency stop5. Battery 12. Hydraulic fluid tank 19. Emergency stop
6. Diesel engine 13. Hydraulic fluid filter6. Diesel engine 13. Hydraulic fluid filter
7. Water tank 14. Hydraulic fluid level glass7. Water tank 14. Hydraulic fluid level glass
59
