Technical specifications
ICC1300-1EN3.pdf 2011-10-10
ROPS-bolts which are to be torque tightened
must be dry.
ROPS-bolts which are to be torque tightened
must be dry.
ROPS - bolts
Bolt dimensions : M16 (PN 902889)Bolt dimensions : M16 (PN 902889)
Strength class : 10.9Strength class : 10.9
Tightening torque : 192 Nm, torque class 2
(Dacromet treated)
Tightening torque : 192 Nm, torque class 2
(Dacromet treated)
Hydraulic system
Opening pressure MPaOpening pressure MPa
Drive system 35,0Drive system 35,0
Supply system 2,5Supply system 2,5
Vibration system 20,0Vibration system 20,0
Control systems 17,0Control systems 17,0
Brake release 1,5Brake release 1,5
18
