Dynapac CC1300 - Hydraulic Reservoir, Level Check - Filling

Maintenance - 10h
ICC1300-1EN3.pdf 2011-10-10
Hydraulic reservoir, Level check - Filling
1
Fig. Hydraulic fluid tank
1. Sight glass
Check that the level is between the min and max
markings. Top up with hydraulic fluid as per lubricant
specifications if level is too low.
1
Fig. Engine compartment
1. Hydraulic fluid refilling
Open the engine hood and unscrew the filler cap, top
up with hydraulic fluid (as per lubricant specification) if
the level is too low.
64
