Operation
ICC1300-1EN3.pdf 2011-10-10
Operator position
1
2
3
4
Fig. Driver seat
1. Seat belt
2. Safety rails
3. Rubber element
4. Anti-slip
If an ROPS (Roll Over Protective Structure) is fitted to
the roller, always wear the seat belt (1) and wear a
protective helmet.
Always replace the seat belt (1) if it shows signs of
wear or has been subjected to excessive strain.
Always replace the seat belt (1) if it shows signs of
wear or has been subjected to excessive strain.
Check that the platform's rubber elements (3) are
in good condition. If the elements are worn this
will have a negative effect on comfort.
Check that the platform's rubber elements (3) are
in good condition. If the elements are worn this
will have a negative effect on comfort.
Ensure that the anti-slip (4) on the platform is in
good condition. Replace where anti-slip friction is
poor.
Ensure that the anti-slip (4) on the platform is in
good condition. Replace where anti-slip friction is
poor.
36
