D 10 15
Item Designation Brief description
27
Left auger
"MANUAL"
conveying
direction
outwards / inwards
Pushbutton function:
- Left switch position:
Manual start of the conveying function,
Conveying direction outwards.
- Right switch position:
Manual start of the conveying function,
Conveying direction inwards.
A
For manual triggering, the auger function must be
switched to "AUTO" or "MANUAL"
A
On manual triggering, the automatic function is overrid-
den with reduced delivery capacity.
f
On actuation, heed danger zones of moving parts of
the vehicle!
28
Right auger
"MANUAL"
conveying
direction
outwards / inwards
Pushbutton function:
- Left switch position:
Manual start of the conveying function,
Conveying direction inwards.
- Right switch position:
Manual start of the conveying function,
Conveying direction outwards.
A
For manual triggering, the auger function must be
switched to "AUTO" or "MANUAL"
A
On manual triggering, the automatic function is overrid-
den with reduced delivery capacity.
f
On actuation, heed danger zones of moving parts of
the vehicle!
