B 14
5.7 Performance data F2500CS
Screed used
Basic width
(without cut-off shoes)
Minimum paving width
(with cut-off shoe)
Continuously hydraulically
adjustable up to
Maximum paving width
(with extension parts)
V5100TV 2.55 2.00 5.10 8.10 m
V6000TV 3.00 2.00 6.00 9.00 m
Transport speed 0 - 4 km/h
Operating speed 0 - 30 m/min
Paving height -150 - 320 mm
Max. grain size 40 mm
Theoretical paving performance 750 t/h
