Item Designation Brief description
38
Retract / extend
left levelling
cylinder
Pushbutton function:
- Upper switch position:
Retract left levelling cylinder.
- Lower switch position:
Extend left levelling cylinder.
f
On actuation, heed danger zones of moving parts of
the vehicle!
39
Retract / extend
right levelling
cylinder
Pushbutton function:
- Upper switch position:
Retract right levelling cylinder.
- Lower switch position:
Extend right levelling cylinder.
f
On actuation, heed danger zones of moving parts of
the vehicle!
