D 10 31
Item Designation Brief description
70 Not used
71 Not used
72
Error message
with engine stop
(red)
Lights up when a serious error has occurred on the engine.
The engine is automatically shut down for safety.
A
The error code can be retrieved using the "Call up er-
ror/malfunction" switch.
A
Lights up for a few seconds once the ignition has been
switched on for checking purposes.
73 Not used
74
Indicator lamp
hydraulic filter
Lights up when the hydraulic filter needs replacing.
A
Replace filter element acc. to Maintenance Instructions!
75
Travel drive error
message
Lights up if there is a fault in the travel drive or if an actuated
emergency stop button prevents the machine from starting.
A
Warning lamp goes off as soon as the error has been
remedied.
76
Indicator lamp
Air filter
Lights up if the air filter needs replacing.
A
Replace filter element acc. to Maintenance Instructions!
