D 10 43
Item Designation Brief description
93
Retract / extend
left / right levelling
cylinder
Pushbutton function:
- Upper switch position:
Retract left / right levelling cylinder.
- Lower switch position:
Extend left / right levelling cylinder.
f
On actuation, heed danger zones of moving parts of
the vehicle!
94
Levelling
Operating mode
"AUTO" /
"MANUAL"
Detent switch function:
- Upper switch position:
Operating mode "MANUAL": height adjustment is
carried out using the corresponding function switches
on the remote control or operating panel.
- Lower switch position:
Operating mode "AUTO": height adjustment is carried
out automatically via the connected grade
control system.
95
Retract / extend
left / right screed
Pushbutton function:
- Switch position in the corresponding direction:
extend or retract left / right screed half
f
On actuation, heed danger zones of moving parts of
the vehicle!
96 Socket
A
For connecting with the corresponding socket on the
side shield.
