C 10 14
The protective roof can be raised and
lowered with a manual hydraulic pump.
A
The exhaust pipe is lowered or raised to-
gether with the roof.
- Connect the pump lever (1)
to the pump (2).
- Tighten bolts (3) on both sides
of the roof.
- Operate the pump lever (1) until the
roof has reached the upper or lower
limit position.
- Set bolts (3) in the respective posi-
tion on both sides of the roof.
