D 10 5
Item Designation Brief description
10 Lights
Lights up instrument panel A/B when the parking light
is switched on
11
Emergency stop
button
Press in an emergency (danger to persons, impending colli-
sion, etc.)!
- Pressing the emergency stop button switches off the en-
gine, the drives and the steering system.
Making way, lifting the screed or other actions are then no
longer possible! Danger of accidents!
- The emergency stop button does not shut off the gas heat-
er system.
Close the main shut-off valve and the valves on the bottles
by hand!
- To restart the engine, the button must be pulled out again.
12
Engine speed
adjuster
Continuously variable engine speed setting
(if drive lever is extended).
Min. setting: Idling speed
Max. position: Nominal speed
A
For paving, select the rated speed; reduce the speed
for transportation.
A
The automatic speed control keeps the set speed con-
stant even under a load.
13
Straight-ahead
travel synchronisa-
tion
Using this potentiometer, both chains can be synchronised for
straight-ahead travel while driving:
- Set the steering to position "0"; then adjust the potentiom-
eter until the paver finisher is travelling straight ahead.
A
This function is only active if the vehicle is not
equipped with automatic synchronisation or the auto-
matic synchronisation system is defective.
