D 10 9
Item Designation Brief description
17 Ignition lock
To activate the ignition voltage by turning the key.
- Switch off by turning the key back to its starting position.
A
On shutting off the vehicle, first switch off the ignition,
then deactivate the main switch.
A
Before the main battery switch is deactivated, a period
of at least 100 seconds must elapse after switching off
the vehicle.
18
Travel drive
preselector
For setting the maximum speed that can be reached when the
drive lever is at its stop.
A
The scale roughly matches the speed in m/min
(during paving).
m
The vehicle must not travel at max. transport speed
when the hopper is full!
f
The vehicle speed cannot be reduced to "0" with the
preselector. The vehicle advances slightly with deflect-
ed drive lever, even if the travel drive preselector is set
to zero!
19
Steering
potentiometer
The steering wheel movement is transferred electrohydraulically.
A
For precise adjustments (position "0" = straight-ahead),
see the straight-ahead travel synchronisation.
For turning on the spot, see switch (Turning on the spot).
20 Horn
Press in the case of emergencies and to indicate when the ve-
hicle starts to move!
A
The horn can also be used to communicate acoustical-
ly with the truck driver for material loading!
21
Operating hours
counter
The operating hours are only counted while the engine
is running.
Heed the maintenance intervals (see chapter F).
22 Fuel gauge
Always heed the fuel gauge.
m
Do not completely empty the diesel tank! Otherwise,
the entire fuel system must be bled.
