Dynapac LP 650 - INSTRUMENTS AND CONTROLS; Control Lever and Handle Locations; Engine and System Controls; Indicator Lamps and Fluid Checks

13
LP 650/750 — ILP650EN1
INSTRUMENTS AND CONTROLS
1. Lever for forward/reverse drive
2. Lever for vibration ON and OFF
3. Push-stop
4. Parking brake
5. Locking hook, handle
6. Refuelling
7. Throttle
8. Ignition key
Operating controls
L000004A
9. Aperture for starting-handle
10. Control lamp, charging
11. Control lamp, oil pressure
12. Oil dipstick
13. Sight glass, hydraulic fluid
14. Shut-off cock, sprinkler
15. Filler cap, sprinkler
= Accessories
9
7
21 34 15
11
5
6
10 812
14 13
L000024A
L000025A
