Dynapac LP 650 - WARNING SYMBOLS; Warning Symbol Definition; Caution Symbol Definition; SAFETY INSTRUCTIONS

2
LP 650/750 — ILP650EN1
WARNING Indicates danger or hazardous
procedure that could result in serious or fatal
personal injury if the warning is ignored.
CAUTION Indicates danger or hazardous
procedure that could result in damage to
machine or property if the warning is ignored.
Carefully study the safety instructions in this
manual before operating. Always follow the
safety instructions and keep this manual
easily accessible.
Read the entire manual before starting the
machine and before any service work.
Ensure good ventilation (air extraction) if the
engine is run indoors.
CONTENTS
WARNING SYMBOLS
SAFETY INSTRUCTIONS
CALIFORNIA
Proposition 65 Warning
Diesel engine exhaust and some of its
constituents are known to the State
of California to cause cancer, birth
defects, and other reproductive harm.
Sida
General ............................................................................ 3
Machine plate ................................................................... 3
Safety instructions (For all Light products) .................... 4-6
Driving near an edge........................................................ 7
Safety decals, Location/Description ............................. 8, 9
Fuel and lubricants......................................................... 10
Technical data ................................................................ 11
Technical data – Dimensions ......................................... 12
Instruments and controls................................................ 13
Handle position .............................................................. 14
Control lamps (Accessories) .......................................... 14
Operation ....................................................................... 15
Operation – manual start................................................ 16
Operation – electric starter (Accessories) ...................... 17
Lifting, transportation and towing .................................. 18
Maintenance – Service points .................................. 19, 20
Maintenance – Every 10 hours of operation ............ 21, 22
Maintenance – Every 250 hours of operation .......... 23, 24
Maintenance – Every 500 hours of operation .......... 25, 26
