23
LP 650/750 — ILP650EN1
MAINTENANCE – EVERY 250 HOURS OF OPERATION
Right side of engine
1. Drain plug
2. Drain hose
3. Oil filter
Diesel engine
– Oil and filter change
3
See engine manual.
The air filter need normally only be cleaned or changed
when the filter indicator shows that the filter is clogged,
ie, on condition that the indicator is working properly.
The filter element may be cleaned a couple of times
but must be replaced at least every two years.
If the filter is contaminated by dry dust, tap the filter
against the palm of the hand until all loose dust is
dislodged and then blow it from the inside with com-
pressed air at a pressure of maximum 5 bar (72 psi) to
remove any remaining dust. The filter must be replaced
if it is wet or oily.
Air cleaner
Air cleaner
– Checking/Cleaning
L000019A
See engine manual.
Engine valve clearance
– Checking/Adjusting
See engine manual.
Engine cooler system
– Cleaning
See engine manual.
Danger - hot oil!
Dispose of waste oil in an environment friendly
manner.
1. Drain off engine oil only when the engine is warm.
2. Unscrew the drain plug (1) and allow all of the oil to
drain completely. Use the accompanying hose (2)
to drain the oil.
3. Screw in the drain plug and tighten it.
4. Release and change the oil filter (3).
5. Fill with fresh engine oil of suitable grade and
viscosity to the maximum mark on the dipstick.
L000026A
1
2
