14
LP 650/750 — ILP650EN1
HANDLE POSITION
Operation/transport modes:
The handle has two modes. Press the catch (1) and
lower the handle to the lower position to operate the
machine. Raise the handle and push it into the latched
position to transport the machine.
Hold the handle while releasing the catch.
If the roller has an electric starter, there will be two
warning lamps: one for oil pressure (1) and one for
charging (2), next to the ignition key.
The charging and oil pressure lamps must be
extinguished during normal operation. If the
lamps do not go out, stop the machine and
take corrective action.
2
Warning lamps
1. Oil pressure lamp
2. Charging lamp
1
CONTROL LAMPS (ACCESSORIES)
Operation mode of the handle
L000027A
L000025A
L000021A
1
