16
WLT6000-1EN1
DIASSEMBLY THE CRANK CASE
7. Dismantle of pinion (10).
Remove snap ring (11) as holding pinion. Remove
pinion shaft from gear housing by hitting the pinion
shaft from the gear side using a steel bar and a
plastic hammer.
Fig. 31 Crankshaft
10. Clutch drum
11. Snap ring
10
11
W000045A
