7
WLT6000-1EN1
The air cleaner must be clean before making
any adjustment. The engine must be warm
before adjusting the speed.
1
1
CARBURETOR LT 6000
Revs:
Idling revs 1550 ± 150 v/min
Engagement revs of
centrifugal clutch about 2500 rpm
Operating speed about 3750 rpm
Idle speed adjustment
1. Start the engine and allow it to warm up to normal
operating temperature.
2. With the engine idling, turn the throttle stop screw to
obtain yhe standard idle speed.
Fig. 5 Carburetor
1. Throttle stop screw
Adjustment of carburetor LT 6000
CARBURETOR LT 7000
Adjustment of carburetor LT 7000
The air cleaner must be clean before making
any adjustment. The engine must be warm
before adjusting the speed.
Revs:
Idling revs 1400 ± 150 v/min
Engagement revs of
centrifugal clutch about 2500 rpm
Operating speed about 3600 rpm
1. Start the engine and allow it to warm up to normal
operating temperature.
2. With the engine idling, turn the throttle stop screw to
obtain the standard idle speed.
Fig. 6 Carburetor
1. Throttle stop screw.
W000006A
W000008A
