Assembling Your Piano (Upright piano)
Attaching the both legs and pedal box assembly
Assembling the stand
Securely combine both legs(a,b) and pedal
box(c) by using four bolts(f) for pedal box.
For pedal stability, rotate the adjusters on
the bottom of the pedal assembly until
they come in firm contact with the floor
surface.
2
Attach the rear plate(d) to the legs and
pedal box using two bolts(h) and four
bolts(f) for rear plate.
Assembling Your Piano(Upright Piano)
