Dynatron® 850plus & 550plus
Installation & Features
9
time will have yellow LEDs). The Time display can also display the pulse rate and width
for Russian and biphasic treatments, as well as the frequencies for interferential,
premodulated, and microcurrent treatments, and pulse rate for high volt. The treatment
parameters for any treatment in progress may be displayed at any time by first using the
channel toggle key to choose the desired channel then using the Time toggle key to select
the desired parameter (Time, Freq, Rate, Width).
6. CHANNEL TOGGLE KEY(CH): When a treatment is in progress, you can press this
key to choose an output channel and display the parameters for the treatment being
delivered by that channel. When a channel light is GREEN, the displays show the
settings for that channel. The available options depend on the modality selected. When
two or more treatments are in progress simultaneously, the toggle key is used to select the
channel you wish to view.
7. CHANNEL SELECTIONS: These lights indicate which output channels are currently in
use. A solid GREEN light indicates current is being delivered to that channel; the time,
intensity and other treatment parameters for that channel are also displayed. A solid
YELLOW light indicates a channel is in use and delivering current, but the time, intensity,
and treatment parameters are not displayed at this time (only one channel’s time and
intensity may be displayed at a time). Flashing green or flashing yellow indicate the “off”
segment of a biphasic, Russian or high volt treatment cycle. The channel’s intensity and
other treatment parameters may only be modified when it has a green indicator light. Press
the Channel Toggle key (CH) to select a channel to be viewed.
8. TIME TOGGLE KEY: Press this key to display various treatment parameters in the
Time display including Time (treatment time), Freq (frequency), Rate (pulse rate), and
Width (pulse width). Available options during a given treatment or treatment setup
depend on the modality selected.
9. TIME GROUP SELECTIONS: These lights indicate the parameters that are displayed
(one at a time) in the Time display. The default selection is the treatment time. Press the
Time toggle key to select the desired option (available options depend on the modality
selected). When a parameter is selected, its indicator light is green, its value is displayed
in the Time display above, and the time arrow keys may be used to change the value.
The device returns to the Time display after 10 seconds with no key presses.
10. POWER-INTENSITY DISPLAY: This display is used to display the treatment power (for
ultrasound) or intensity (for all other modalities) for the currently selected channel (the
selected channel is indicated by the green LED—all other channels in use at the time will
have yellow LEDs). Press the channel toggle key to select the desired channel to be
viewed.
11. POWER - INTENSITY ARROW KEYS: The arrow keys are used to increase/decrease
the intensity or power of one treatment. Changes made to power and intensity affect only
the currently selected channel (the selected channel is indicated by the green LED—all
other channels in use at the time will have yellow LEDs). Press the channel toggle key to
select the desired output channel. The arrow keys may then be used to change the
intensity or power for that channel.
