Transformer Compatibility
SECTION 4: TRANSFORMER COMPATIBILITY
It is important that the PAU, the Dynamometer Coil, and the Transformer are compatible.
The following tables can be used to check these components in your system.
Wall Mount PAU, Coil and Transformer Compatibility Table
PAU Transformer Coil
Wall Mount PAU
Model No.
Current
Specications
Facility Power
(Primary)
PAU Input Power
(Secondary)
Calculated
Transformer VA
Max. Volts
DC Output
Max. Coil
Current
UEC-PAU-15-W01 15 amp 208 240 3,600 200 15
15 amp 208 277 4,155 250 15
UEC-PAU-15-W02 15 amp 240 240 3,600 200 15
15 amp 240 277 4,155 250 15
UEC-PAU-15-W03 15 amp 480 240 3,600 200 15
15 amp 480 277 4,155 250 15
UEC-PAU-15-W04 15 amp 208 480 7,200 400 15
UEC-PAU-15-W05 15 amp 240 480 7,200 400 15
UEC-PAU-15-W06 15 amp 480 480 7,200 400 15
UEC-PAU-30-W01 30 amp 208 240 7,200 200 30
UEC-PAU-30-W02 30 amp 240 240 7,200 200 30
30 amp 480 480 14,400 400 30
UEC-PAU-30-W03 30 amp 208 277 8,310 250 30
UEC-PAU-30-W04 30 amp 240 277 8,310 250 30
UEC-PAU-30-W05 30 amp 480 240 7,200 200 30
UEC-PAU-30-W06 30 amp 480 277 8,310 250 30
UEC-PAU-30-W07 30 amp 208 480 14,400 400 30
UEC-PAU-30-W08
30 amp 240 480 14,400 400 30
UEC-PAU-50-W01 50 amp 208 240 12,000 200 50
50 amp 208 277 13,850 250 50
UEC-PAU-50-W02 50 amp 240 240 12,000 200 50
50 amp 240 277 13,850 250 50
UEC-PAU-50-W03 50 amp 480 240 12,000 200 50
UEC-PAU-50-W03 50 amp 480 277 13,850 250 50
UEC-PAU-50-W04 50 amp 480 480 24,000 400 50
UEC-PAU-100-W01 100 amp 480 240 24,000 200 100
