RACK MOUNT START-UP
Inter-Loc V Start-Up
1. Validate the conguration listed on the cover of the manual and exterior of unit are
identical and appropriate for your application. If these values do not match or are not
appropriate for your application, please contact Dyne Systems.
2. Verify the integrity of power wiring (i.e. no shorts to ground, verify coil resistance, etc).
3. Power up the Inter-Loc V / OCS.
4. Apply power to the PAU.
5. The following will appear on the display for ~3 seconds:
Eddy-Current PAU
XX.X A max VX.X
XX.XA - The maximum current of the PAU (15, 30, 50, 100)
VX.X - The version of rmware
The display will then change to the following:
Not Self Res.
Reset Required
Not Self Res. Reset Required - Requires a manual reset after the application of
power or after a fault condition has occurred.
6. Push the RESET button on the OCS to Initiate the System.
7. The following will appear on the display:
PAU: Ok Off
0% 0.0A
PAU:Ok - signies everything is okay, or else the word Fault is displayed (refer to
Rack Mount Troubleshooting Guide on page 26).
Off - PAU is not enabled
% - Percentage of command signal 0-10VDC or 0-20mA
A - Amount of current being applied to coil
If Fault is displayed, power down the Inter-Loc V and PAU, correct the fault, and then go
back to Step 3.
8. Perform the Max Current adjustment if this is the rst time use. (See Appendix A, p.32
for setting Max Current.)
9. Your DS820F PAU is ready for use.
