Troubleshooting - Customer Support

Terminal Connection Description Function

Power Connections for 15A Rack Mount

ECPAU Power-A AC Input (Field Power) Input: Connection from secondary side of transformer

ECPAU Power-B AC Input (Field Power) Input: Connection from secondary side of transformer

ECPAU Power-C Ground Ground connection for 120VAC

ECPAU Power-D AC Input (120V Hot) Input: Connection from secondary side of transformer

ECPAU Power-E AC Input (120V Neutral) Input: Connection from secondary side of transformer

Power Connections for 30A Rack Mount

ECPAU Power-A AC Input (Field Power) Input: Connection from secondary side of transformer

ECPAU Power-B AC Input (Field Power) Input: Connection from secondary side of transformer

ECPAU Power-C Ground Ground connection for 120VAC

ECPAU Power-D AC Input (120V Hot) Input: Connection from secondary side of transformer

ECPAU Power-E AC Input (120V Neutral) Input: Connection from secondary side of transformer

Field Connections for 15A Rack Mount

ECPAU Power-F Field Output: Connection to dynamometer coil

ECPAU Power-G Field Output: Connection to dynamometer coil

ECPAU Power-H Ground Ground connection to dynamometer coil

Field Connections for 30A Rack Mount

Field Power-A Field Output: Connection to dynamometer coil

Field Power-B Field Output: Connection to dynamometer coil

Field Power-C Ground Ground connection to dynamometer coil

Table 8.3 - Faults / Troubleshooting, Rack Mount Signals

Note: For further troubleshooting assistance, please contact Dyne Systems.

SECTION 9: CUSTOMER SUPPORT

Dyne Systems Customer Support can be reached at 1-800-657-0726 or by

Email at sales@dynesystems.com. Please have the serial and model numbers available for

all products.
