DyneSystems DS820F - Wall Mount Signals

Faults/Troubleshooting
Terminal Connection Description Function
TB6-1 Cooling Fan Output: 120VAC for cabinet cooling fan
TB6-2 Cooling Fan Output: 120VAC for cabinet cooling fan
TB6-3 Field Output: Connection to dynamometer coil
TB6-4 Field Output: Connection to dynamometer coil
TB6-5 AC Input (from secondary) Input: Connection from secondary side of transformer
TB6-6 AC Input (from secondary) Input: Connection from secondary side of transformer
TB6-7 AC Output (to primary) Output: Connection to primary side of transformer
TB6-8 AC Output (to primary) Output: Connection to primary side of transformer
L1 Main AC Input Input: Connection to facility main power
L2 Main AC Input Input: Connection to facility main power
GND Ground Input: Connection to facility main ground
Table 8.2 - Faults / Troubleshooting, Wall Mount Signals
Note: For further troubleshooting assistance, please contact Dyne Systems.
