CHAPTER 3
Folding Ramp
Above Ground Model 250i Motorcycle Dynamometer Installation Guide
3-30
2 Remove the four 1/4-inch button-head bolts from the top of the dyno.
3 Remove the two 3/8-inch button-head bolts from the back of the dyno.
Figure 3-33: Remove the Bolts from the Dyno
remove two
back bolts
remove four
top bolts
