Dynojet 200 - Installing the Blower Mounts

HIGH PRESSURE BLOWER INSTALLATION
Model 200i/250i In Ground Blower Installation
High Pressure Blower Installation Guide
10
INSTALLING THE BLOWER MOUNTS
1 Secure the blower mount to the pit floor using four 3/8 x 1.25-inch button-head
flange bolts.
Note: The left blower mount is secured under the support arm (if present) and
junction box. For complete dyno installation instructions, refer to the In Ground
Model 250iP Motorcycle Dynamometer Installation Guide
P/N 98200053.
2 Secure the right blower mount to the pit floor using four 3/8 x 1.25-inch button-
head flange bolts.
Figure 5: Install the Blower Mounts
PD159
support arm
blower mount
junction box
blower mount
(under support arm)
