HIGH PRESSURE BLOWER INSTALLATION
Main Dyno Power
High Pressure Blower Installation Guide
4
MODEL 200I/250I MAIN DYNO POWER—IN GROUND
Always turn the power off when connecting and disconnecting cables.
1 Use the main breaker to turn power on and off to the dyno.
The main breaker is located inside the CPI door. When the handle is in the down
position all power into the dyno is turned off.
2 Disconnect the power plug to ensure all power has been removed from the dyno
before performing certain installation procedures.
Figure 2: Model 200i/250i Main Dyno Power—In Ground
