HIGH PRESSURE BLOWER INSTALLATION
Stand Alone Blower Installation
High Pressure Blower Installation Guide
14
INSTALLING THE BLOWER AND BASE ASSEMBLIES
Repeat the following steps for each blower and base assembly.
1 Secure the handle to the blower, if not already installed.
1a Remove the two 5/16-inch bolts from the blower.
1b Secure the handle to the blower using the 5/16-inch bolts you just removed.
2 Insert the pin on the blower assembly into the stand alone base.
3Tighten the clamp lever.
Figure 8: Secure the Blower to the Base
handle
base
bolt
blower assembly
clamp lever
