HIGH PRESSURE BLOWER INSTALLATION
Main Dyno Power
Version 4 High Pressure Blower Installation Guide
MAIN DYNO POWER
Many instructions in this guide will require you to connect or disconnect the power to
the dyno as part of the installation process. Use the following steps to connect and
disconnect power to the dyno.
MODEL 200I/250I MAIN DYNO POWER—ABOVE GROUND
Always turn the power off when connecting and disconnecting cables.
1 Use the main breaker to turn power on and off to the dyno.
The main breaker is located inside the CPI door. When the handle is in the down
position all power into the dyno is turned off.
2 Disconnect the power plug to ensure all power has been removed from the dyno
before performing certain installation procedures.
Figure 1: Model 200i/250i Main Dyno Power—Above Ground
