C-3
MODEL 200/250 BLOWER INSTALLATION
Installation
Version 4 High Pressure Blower Installation Guide
MODIFYING THE TIRE STOP
Older dynos may not have the four holes on the tire stop needed to mount the
extension arm assembly; you will need to modify the tire stop before continuing with
the blower installation instructions. Refer to
Figure C-1 for hole size and placement.
Figure C-1: Modify the Tire Stop
