HIGH PRESSURE BLOWER INSTALLATION
Model 200i/250i Above Ground Blower Installation
Version 4 High Pressure Blower Installation Guide
MODEL 200I/250I ABOVE GROUND BLOWER INSTALLATION
The high pressure blower supplies air to cool the bike’s engine. This section will walk
you through the blower installation procedures. For complete dyno installation
instructions, refer to the Above Ground Model 250i Motorcycle Dynamometer
Installation Guide
P/N 98200049.
The following table lists all of the parts included in the High Pressure Blower
Installation kit (P/N 76722003). Check your kit against the parts listed to make sure
you have received all of the parts. If any part is missing, contact Dynojet Technical
Support.
part description part description
washer 1.87 x 1.25 ID x .12
thick. poly (4)
P/N 26215520
blower assembly, right
P/N 61300000
blower assembly, left
P/N 61300003
washer 1.87 x 1.25 ID x .25
thick, poly (2)
P/N 26215521
upper blower arm assembly
P/N 63400000
clamp lever, 3/8-16 x 3/4" (6)
P/N 35712991
lower blower arm assembly
P/N 63400001
clamp lever, 3/8-16 x 1.5" (2)
P/N 35712992
cable, blower assembly
power (2)
P/N 76950301
