35
Upper Main Rotor Blade Tracking Adjustment
Caution: Be sure to maintain a safe distance from the helicopter (approximately 10–15 feet) when
tracking the Upper Main Rotor Blade.
Your Blade™ CX2 is equipped with an adjustable linkage between the Stabilizer Flybar and Upper Main Rotor
Blade. This linkage allows you to adjust the tracking of the upper main rotor blade for smoother and more
stable flight performance.
• You can check the upper main rotor blade tracking either on the ground or in the air at eye level. It might be a
good idea to have an assistant on hand to help sight the blade tracking.
• Once the main rotor blades have been brought up to speed, note whether the tips of the upper main rotor blade
are tracking in the same plane or not.
