37
Channel 5 Knob Description and Function
The transmitter included with your Blade™ CX2 is equipped with an optional-use “Channel 5” knob (labeled as
“CH 5”) on the top right panel.
This knob allows you to control function of the transmitter’s 5th channel. This channel remains unused for
flying the Blade CX2, however, it is available for use in controlling a variety of potential optional features
including actuation of an additional servo or certain electronic components. It allows full proportional control
of the 5th channel from approximately 0–100% travel.
The knob can be operated in either direction for control. You can use either the most clockwise (+) or most
counterclockwise (-) position for 0 or 100% travel, and you will achieve approximately 50% travel with the knob in
the middle position, pointing directly to the rear of the transmitter.
