E-FLITE BLADE CX2 - Exploded View Parts Listing

46
001 .......................... Stabilizer Flybar Rubber Tip (2) ......................................EFLH1219
002 .......................... Stabilizer Flybar Weight (2) ...........................................EFLH1219
003 .......................... Stabilizer Flybar (1) .......................................................EFLH1219
004 .......................... Upper Main Blade (2) ....................................................EFLH1221
005 .......................... 1.2 x 6mm Screw (5) ....................................................EFLH1225
006 .......................... Stabilizer Flybar Hub/Holder (1) .....................................EFLH1242
007 .......................... Upper Rotor Head & Inner Shaft (1) ................................EFLH1242
008 .......................... Stabilizer Flybar Linkage (1) ...........................................EFLH1219
009 .......................... Bearing 2mm x 6mm x 3mm (2) ....................................EFLH1121
010 .......................... Bearing Holder (1) ........................................................EFLH1217
011 .......................... Outer Shaft (1)..............................................................EFLH1213
012 .......................... Lower Rotor Head (1) ....................................................EFLH1217
013 .......................... M2 x 2.5mm Screw (5) .................................................EFLH1225
014 .......................... Lower Main Blade (2) ...................................................EFLH1220
015 .......................... Lower Rotor Head/Swash Linkage (2) ............................EFLH1217
016 .......................... Upper Swashplate (1) ....................................................EFLH1216
017 .......................... Bearing 7mm x 13mm x 4mm (1) ..................................EFLH1216
018 .......................... Lower Swashplate (1) ....................................................EFLH1216
019 .......................... Servo Pushrod Control Link (2).......................................EFLH1218
020 .......................... Outer Shaft Retaining Collar (1) ......................................EFLH1214
021 .......................... Main Motor Left (1) .......................................................EFLH1210
Main Motor Right (1) .....................................................
EFLH1211
022 .......................... Pinion Gear Left (1) .......................................................EFLH1210
Pinion Gear Right (1) .....................................................
EFLH1211
023 .......................... Servo Mount (1) ............................................................EFLH1254
024 .......................... Body Mount Rod (2) ......................................................EFLH1226
025 .......................... Super Sub-Micro Servo (2) .............................................EFLRS60
026 .......................... 1.7 x 4mm Screw (8) ....................................................EFLH1225
027 .......................... Bearing 4mm x 8mm x 3mm (2) ....................................EFLH1215
028 .......................... Servo Pushrod (2) .........................................................EFLH1218
029 .......................... 4-in-1 Control Unit (1) ....................................................EFLH1024
030 .......................... Main Frame (1) .............................................................EFLH1254
031 .......................... M2 x 4mm Screw (6) ....................................................EFLH1225
032 .......................... Front Body (1) ..............................................................EFLH1255
033 .......................... Rear Body (1) ...............................................................EFLH1256
034 .......................... Outer Shaft Main Gear (1) ..............................................EFLH1213
035 .......................... Inner Shaft Main Gear (1) ...............................................EFLH1243
036 .......................... Inner Shaft Retaining Collar (1) .......................................EFLH1214
037 .......................... Battery Support Rear (1) ...............................................EFLH1223
038 .......................... Battery Support Front (1) ...............................................EFLH1223
039 .......................... Battery Support Joiner (2) .............................................EFLH1223
040 .......................... Body Mount Grommet (4) ..............................................EFLH1226
041 .......................... Battery Pack (1)............................................................EFLB0990
042 .......................... Landing Skid Right (1) ...................................................EFLH1222
043 .......................... Landing Skid Left (1) .....................................................EFLH1222
044 .......................... Step Washer (1) ............................................................EFLH1225
Exploded
View
Reference
Number
Description
(Quantity Required)
Included In Item
Number
Exploded View Parts Listing
Please see your favorite retailer or visit our web site (www.E-fliteRC.com) to find the latest in new replacement
and option parts releases for your Blade CX2.
