E Instruments E4500-N User Manual

39
K000000000EJ 023826A0 100714
9.3.5 Configuration→Instrument→CO dilutor
CONTEXT KEY FUNCTION
Enters edit mode of the selected parameter.
Confirms the modification. OK
Configuration
CO dilutor
07/08/14
10:00
Limit
ppm
1500
Mode
auto
Available settings: auto, on or off
Threshold that activates the dilution pump (available only if the "Mode" parameter is set o
"auto".
→
KEY FUNCTION
Activate the context keys shown on the display.
Select each line displayed (the line selected is red).
In edit mode, it sets the desired value.
When pressed in modify mode cancels the selection made, otherwise
returns to the previous screen.
Enters edit mode of the selected element and then confirms the change.
