40
K000000000EJ 023826A0 100714
9.3.6 Configuration→Instrument→Micromanometer
CONTEXT KEY FUNCTION
Enters edit mode of the selected parameter.
Confirms the modification.
OK
Sets the input used for the test: P+ o P-
→
KEY FUNCTION
Activate the context keys shown on the display.
In edit mode, it sets the desired input.
When pressed in modify mode cancels the selection made, otherwise
returns to the previous screen.
Enters edit mode of the selected element and then confirms the change.
Configuration
Micromanometer
07/08/14
10:00
Inlet
P+
